Processor Module PM582 PM583-ETH PM585-ETH
ETH = Ethernet - ETH onboard with web server,
SNTP and IEC60870-5-104
protocol
RJ45 -
ARCNET = ARCNET BNC -
Number of external communication modules Up to 4 communication modules like PRO-
FIBUS DP, Ethernet, CANopen. There are no
restrictions concerning the communication
module types and communication module com-
binations (e.g. up to 4 PROFIBUS DP commu-
nication modules are possible)
Ethernet - 10/100 base-TX, 1x RJ45
socket,
provided on TB5x1-ETH
LEDs, LCD display, 8 Function Keys For RUN/STOP switchover, status displays and
diagnosis
Number of timers Unlimited
Number of counters Unlimited
Programming languages:
Structured Text ST x
Instruction List IL x
Function Block Diagram FBD x
Ladder Diagram LD x
Sequential Function Chart SFC x
Continuous Function Chart (CFC) x
1
): up to 7 I/O terminal units before PS501 V1.2 and processor module firmware before V1.2.0.
Table 12: PM59x
2
)
Processor Module PM59x-ETH PM59x-
ARCNET
PM59x-ETH
PM59x-2ETH
Program memory flash EPROM and RAM PM590: 2048 kB
PM591/PM592: 4096 kB
Data memory, integrated PM590: 2560 kB,
PM591: 3584 kB, incl. 1536 kB
buffered
PM590: 3072
kB,
PM591/592:
5632 kB, incl.
1536 kB buf-
fered
Expandable memory None None None
Integrated mass storage memory None None PM592-ETH: 4
GB flash disk
Pluggable memory card for:
User data storage x x x
Program storage x x x
Firmware update x x x
Cycle time for 1 instruction:
Device Specifications
Processor Modules > AC500 (Standard)
2019/04/17 3ADR010121, 13, en_US 75
