5-4
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 5 Turn Up Network
NTP-A173 Point-to-Point Network Acceptance Test
Step 4 Verify that the working and protect cards in the 1+1 protection groups correspond to the physical fiber
connections between the nodes, that is, verify that the working card in one node connects to the working
card in the other node, and that the protect card in one node connects to the protect card in the other node.
Step 5 Complete the “DLP-A377 Provision Section DCC Terminations” task on page 20-61 for the working
OC-N port on both point-to-point nodes. Alternatively, if additional bandwidth is needed for CTC
management, complete the “DLP-A378 Provision Line DCC Terminations” task on page 20-62.
Note DCC terminations are not provisioned on the protect ports.
Note If the point-to-point nodes are not connected to a LAN, you will need to create the DCC
terminations using a direct (craft) connection to the node. Remote provisioning is possible only
after all nodes in the network have DCC terminations provisioned to in-service OC-N ports.
Step 6 Complete the “DLP-A214 Change the Service State for a Port” task on page 19-9 to put the protect card
in-service.
Step 7 As needed, complete the “DLP-A380 Provision a Proxy Tunnel” task on page 20-63.
Step 8 As needed, complete the “DLP-A381 Provision a Firewall Tunnel” task on page 20-64.
Step 9 As needed, complete the “DLP-A367 Create a Provisionable Patchcord” task on page 20-51.
Step 10 Verify that timing is set up at both point-to-point nodes. If not, complete the “NTP-A28 Set Up Timing”
procedure on page 4-9 for one or both of the nodes. If a node uses line timing, make its working OC-N
card the timing source. The system will automatically choose the corresponding protect OC-N card as
the protect timing source. This will be visible in the Maintenance > Timing tab.
Step 11 Complete the “NTP-A173 Point-to-Point Network Acceptance Test” procedure on page 5-4.
Stop. You have completed this procedure.
NTP-A173 Point-to-Point Network Acceptance Test
Caution This procedure might be service affecting if performed on a node carrying traffic.
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at one of the point-to-point nodes. The node
(default) view appears. If you are already logged in, continue with Step 2.
Step 2 From the View menu, choose Go to Network View.
Purpose This procedure tests a point-to-point network.
Tools/Equipment Test set/cables appropriate to the test circuit you will create
Prerequisite Procedures NTP-A124 Provision a Point-to-Point Network, page 5-3
Required/As Needed As needed
Onsite/Remote Onsite
Security Level Provisioning and higher
