17-45
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A37 Install the XCVT or XC10G Cards
Note If you insert a card into a slot provisioned for a different card, all LEDs turn off.
Note Alarm LEDs might be on; disregard alarm LEDs until you are logged into CTC and can view the
Alarms tab.
Step 9 Verify that the ACT/STBY LED is amber for standby.
Step 10 Return to your originating procedure (NTP).
DLP-A37 Install the XCVT or XC10G Cards
Note Do not use this procedure to upgrade cross-connect cards. If you are upgrading an XCVT card to an
XC10G, see Chapter 12, “Upgrade Cards and Spans.”
Note When installing cards, let each card boot completely before installing the next card.
Step 1 Open the latches/ejectors of the first XCVT or XC10G card that you will install.
Step 2 Use the latches/ejectors to firmly slide the card along the guide rails until the card plugs into the
receptacle at the back of the slot (Slot 8 or 10).
Step 3 Verify that the card is inserted correctly and close the latches/ejectors on the card.
Note It is possible to close the latches/ejectors when the card is not completely plugged into the
backplane. Ensure that you cannot insert the card any further.
Step 4 Verify the LED activity:
• The red LED turns on for 20 to 30 seconds.
• The red LED blinks for 35 to 45 seconds.
• The red LED turns on for 5 to 10 seconds.
• All LEDs blink once and turn on.
• The ACT/STBY LED turns on.
Purpose This task installs the cross-connect (XCVT/XC10G) cards.
Tools/Equipment XCVT/XC10G (cross-connect) cards
Prerequisite Procedures DLP-A36 Install the TCC2/TCC2P Cards, page 17-42
Required/As Needed Required in non-DWDM shelves.
Onsite/Remote Onsite
Security Level None
