Cisco ONS 15454 Series User Manual

11-4
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 11 Change Card Settings
NTP-A118 Modify Alarm Interface Controller-International Settings
NTP-A118 Modify Alarm Interface Controller-International
Settings
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to change the
AIC-I card settings. If you are already logged in, proceed to Step 2.
Step 2 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Step 3 Perform any of the following tasks as needed:
• DLP-A208 Change External Alarms Using the AIC-I Card, page 19-6
• DLP-A209 Change External Controls Using the AIC-I Card, page 19-7
• DLP-A210 Change AIC-I Card Orderwire Settings, page 19-8
Step 4 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Stop. You have completed this procedure.
NTP-A91 Upgrade DS-1 and DS-3 Protect Cards from 1:1
Protection to 1:N Protection
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to convert the
DS-1 or DS-3 cards from 1:1 to 1:N protection. If you are already logged in, proceed to Step 2.
Step 2 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Purpose This procedure provisions the AIC-I card to receive input from or send
output to external devices wired to the backplane (called external alarms
and controls or environmental alarms), or to change orderwire settings.
Tools/Equipment None
Prerequisite Procedures NTP-A258 Provision External Alarms and Controls on the Alarm Interface
Controller-International, page 7-11
DLP-A83 Provision Orderwire, page 17-84
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This procedure converts DS-1 and DS-3 protect cards from 1:1 to 1:N
protection. This procedure does not apply to DWDM-only nodes.
Tools/Equipment None
Prerequisite Procedures DLP-A71 Create a 1:1 Protection Group, page 17-78
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
