11-6
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 11 Change Card Settings
NTP-A297 Change Card Service State
NTP-A297 Change Card Service State
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to change the
card service state.
Step 2 Click the Inventory tab.
Step 3 Click Admin State for the card you want to change, and choose an Admin state from the drop-down list:
IS (In-Service) or OOS,MT (Out-of-Service,Maintenance).
Step 4 Click Apply.
Step 5 If an error message opens indicating that the card state cannot be changed from its current state, click
OK.
Table 11-1 lists possible card service state transitions based on the Admin State chosen. For more
information about the enhanced state model and card state transitions, refer to the “Administrative and
Service States” appendix of the Cisco ONS 15454 Reference Manual.
Purpose This procedure changes card service state.
Tools/Equipment None
Prerequisite Procedures Chapter 2, “Install Cards and Fiber-Optic Cable”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 11-1 Cisco ONS 15454 Card State Transitions
Admin State Original Service State Next Service State
IS OOS-AUMA,MT & UEQ
(Out-of-Service and Autonomous
Management,Maintenance and
Unequipped)
OOS-AU,UEQ
(Out-of-Service &
Autonomous,Unequipped)
IS OOS-AUMA,MEA & MT
(Out-of-Service and Autonomous
Management,Mismatched Equipment and
Maintenance)
OOS-AU,MEA
(Out-of-Service and
Autonomous,Mismatched Equipment)
IS OOS-MA,MT
(Out-of-Service and
Management,Maintenance)
IS-NR
(In-Service and Normal)
OOS,MT OOS-AU,MEA
(Out-of-Service and
Autonomous,Mismatched Equipment)
OOS-AUMA,MT & UEQ
(Out-of-Service and Autonomous
Management,Maintenance and
Unequipped)
OOS,MT OOS-AU,AINS & UEQ
(Out-of-Service and Autonomous,Auto
In-Service and Unequipped)
OOS-AUMA,MT & UEQ
(Out-of-Service and Autonomous
Management,Maintenance and
Unequipped)
