19-8
Cisco ONS 15454 Procedure Guide, R5.0
September 2005
Chapter 19 DLPs A200 to A299
DLP-A210 Change AIC-I Card Orderwire Settings
DLP-A210 Change AIC-I Card Orderwire Settings
Caution When provisioning orderwire for ONS 15454s residing in a ring, do not provision a complete orderwire
loop. For example, a four-node ring typically has east and west ports provisioned at all four nodes.
However, to prevent orderwire loops, provision two orderwire ports (east and west) at all but one of the
ring nodes.
Tip Before you begin, make a list of the ONS 15454 slots and ports that require orderwire communication.
Step 1 In node view, double-click the AIC-I card to display it in card view.
Step 2 Click the Provisioning > Local Orderwire tabs or the Provisioning > Express Orderwire tabs,
depending on the orderwire path that you want to create. Provisioning steps are the same for both types
of orderwire.
Step 3 If needed, adjust the Tx and Rx dBm by moving the slider to the right or left for the headset type
(four-wire or two-wire) that you will use. In general, you should not need to adjust the dBm.
Step 4 If you want to turn on the audible alert (buzzer) for the orderwire, check the Buzzer On check box.
Step 5 Click Apply.
Step 6 Return to your originating procedure (NTP).
DLP-A212 Create a User Data Channel Circuit
Step 1 In network view, click the Provisioning > Overhead Circuits tabs.
Step 2 Click Create.
Purpose This task changes orderwire settings on the AIC-I card.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This task creates a user data channel (UDC) circuit on the ONS 15454. A
UDC circuit allows you to create a dedicated data channel between nodes.
Tools/Equipment OC-N cards must be installed.
Prerequisite Procedures NTP-A24 Verify Card Installation, page 4-2
DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
