20-77
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A387 Change Line and Threshold Settings for the DS3XM-12 Card
Table 20-5 lists the line thresholds options for DS3XM-12 cards.
Service State (Display only.) Identifies the
autonomously generated state that
gives the overall condition of the port.
Service states appear in the format:
Primary State-Primary State Qualifier,
Secondary State.
• IS-NR—(In-Service and Normal) The
port is fully operational and performing
as provisioned.
• OOS-AU,AINS—(Out-Of-Service and
Autonomous, Automatic In-Service)
The port is out-of-service, but traffic is
carried. Alarm reporting is suppressed.
The ONS node monitors the ports for an
error-free signal. After an error-free
signal is detected, the port stays in
OOS-AU,AINS state for the duration of
the soak period. After the soak period
ends, the port service state changes to
IS-NR.
• OOS-MA,DSBLD—(Out-of-Service
and Management, Disabled) The port is
out-of-service and unable to carry
traffic.
• OOS-MA,MT—(Out-of-Service and
Management, Maintenance) The port is
out-of-service for maintenance. Alarm
reporting is suppressed, but traffic is
carried and loopbacks are allowed.
Line Type Defines the line framing type.
• AUTO FRAME
• ESF - Extended Super Frame
• D4
• UNFRAMED
FDL Mode Defines the fiber data link (FDL) mode
for the port.
• T1.403
• BFDL - Bidirectional FDL
Table 20-4 DS1 Options for the DS3XM-12 Card (continued)
Parameter Description Options
Table 20-5 Line Thresholds Options for the DS3XM-12 Card
Parameter Description Options
Port (Display only.) Display the port number
by DS-3 and corresponding DS-1.
DS-3: 1 – 35
DS-1: 1 – 28
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds.
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds.
