Cisco ONS 15454 Series - NTP- A239 View E-Series Ethernet Maintenance Information

15-17
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 15 Maintain the Node
NTP-A239 View E-Series Ethernet Maintenance Information
Step 3 To view loopback status, click the Maintenance > Loopback tabs.
The Port and Service State columns identify the port number and current service state (In-Service and
Normal [IS-NR], Out-of-Service and Management, Disabled [OOS-MA,DSBLD], or Out-of-Service and
Management, Maintenance [OOS-MA,MT]) for each port. The Loopback Type column identifies the
type of loopback (None, Terminal [Inward], or Facility [Line]) applied to each port on the card.
Step 4 To view Ethernet bandwidth utilization, click the Maintenance > Bandwidth tabs.
Step 5 Click Retrieve Bandwidth Usage.
The current STS bandwidth usage information appears.
Step 6 To view J1 path trace information, click the Maintenance > Path Trace tabs and then click Retrieve.
Stop. You have completed this procedure.
NTP-A239 View E-Series Ethernet Maintenance Information
Note The E-Series Maintenance tab is not implemented in this release.
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66. If you are already logged in, continue with
Step 2.
Step 2 To view spanning tree information, in node view click the Maintenance > Ether Bridge >
Spanning Trees tabs.
Step 3 As needed, complete the following tasks:
• DLP-A309 View the Ethernet MAC Address Table, page 20-4
• DLP-A310 View Ethernet Trunk Utilization, page 20-5
Stop. You have completed this procedure.
Purpose This procedure enables you to view maintenance information for
E-Series Ethernet cards.
Tools/Equipment None
Prerequisite Procedures NTP-A246 Install Ethernet Cards and Connectors, page 2-10
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
