Cisco ONS 15454 Series User Manual

19-43
Cisco ONS 15454 Procedure Guide, R5.0
September 2005
Chapter 19 DLPs A200 to A299
DLP-A260 Set Auto-Refresh Interval for Displayed PM Counts
DLP-A260 Set Auto-Refresh Interval for Displayed PM Counts
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 From the Auto-refresh drop-down list, choose one of six options:
• None: This option disables the auto-refresh feature.
• 15 Seconds: This option sets the window auto-refresh at 15-second time intervals.
• 30 Seconds: This option sets the window auto-refresh at 30-second time intervals.
• 1 Minute: This option sets the window auto-refresh at 1-minute time intervals.
• 3 Minutes: This option sets the window auto-refresh at 3-minute time intervals.
• 5 Minutes: This option sets the window auto-refresh at 5-minute time intervals.
Step 4 Click Refresh. The PM counts for the newly selected auto-refresh time interval appear.
Depending on the selected auto-refresh interval, the displayed PM counts automatically update when
each refresh interval completes. If the auto-refresh interval is set to None, the PM counts that appear are
not updated unless you click Refresh.
Step 5 Return to your originating procedure (NTP).
DLP-A261 Refresh PM Counts for a Different Port
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 In the Port drop-down list, choose a port.
Purpose This task changes the window auto-refresh intervals for updating the
displayed PM counts.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This task changes the window view to display PM counts for another
port on a multiport card.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
