Chapter 20 DLPs A300 to A399
DLP-A388 Change Line and Threshold Settings for the DS3/EC1-48 Cards
Table 20-11 describes the values on the Provisioning > SONET Thresholds tabs for the DS3/EC1-48
card.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (Pbit Near End only;
CPbit, Near and Far End).
SAS Severely errored frame/alarm indication
signal
Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (Pbit Near End only).
AISS Alarm indication signal seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (Pbit Near End only).
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (Pbit Near End only;
CPbit, Near and Far End).
Table 20-10 Electrical Path Threshold Options for the DS3/EC1-48 Card (continued)
Parameter Description Options
Table 20-11 SONET Threshold Options for the DS3/EC1-48 Card
Parameter Description Options
Port (Display only.) DS-3 ports partitioned for
STS
Line 1, STS 1, Line 2, STS 1
Line 3, STS 1, Line 4 STS 1
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
FC Failure count Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
