Cisco ONS 15454 Series User Manual

20-76
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A387 Change Line and Threshold Settings for the DS3XM-12 Card
Table 20-4 describes the values on the Provisioning > DS1 tabs for the DS3XM-12 cards. Refer to the
Cisco ONS 15454 Reference Manual for more information about portless protection on DS3XM-12
cards.
Line Length Defines the distance (in feet) from
backplane connection to the next
termination point.
• 0 - 225 (default)
• 226 - 450
Admin State Sets the port service state unless network
conditions prevent the change.
• IS—Puts the port in-service. The port
service state changes to IS-NR.
• IS,AINS—Puts the port in automatic
in-service. The port service state
changes to OOS-AU,AINS.
• OOS,DSBLD—Removes the port
from service and disables it. The port
service state changes to
OOS-MA,DSBLD.
• OOS,MT—Removes the port from
service for maintenance. The port
service state changes to
OOS-MA,MT.
Table 20-3 Line Options for the DS3XM-12 Parameters (continued)
Parameter Description Options
Table 20-4 DS1 Options for the DS3XM-12 Card
Parameter Description Options
Port (Display only.) Display the port
number by DS-3 and corresponding
DS-1.
DS-3: 1 – 35
DS-1: 1 – 28
Port Name Displays the port name. User-defined, up to 32 alphanumeric/ special
characters. Blank by default.
See the “DLP-A314 Assign a Name to a
Port” task on page 20-8.

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
