1-7
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A4 Remove the Backplane Covers
NTP-A4 Remove the Backplane Covers
Warning
The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Step 1 Complete the “DLP-A10 Remove the Lower Backplane Cover” task on page 17-10.
Step 2 Complete the “DLP-A11 Remove the Backplane Sheet Metal Cover” task on page 17-11.
Step 3 If you plan to install electrical interface assemblies (EIAs), continue with the “NTP-A5 Install the EIAs”
procedure on page 1-7. If not, continue with the “NTP-A6 Install the Power and Ground” procedure on
page 1-9.
Stop. You have completed this procedure.
NTP-A5 Install the EIAs
Purpose This procedure describes how to access the backplane by removing the
covers. The backplane has two sheet metal covers (one on either side)
and a lower backplane cover at the bottom.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Prerequisite Procedures NTP-A2 Install the Shelf Assembly, page 1-5
NTP-A3 Open and Remove the Front Door, page 1-6
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
Purpose This procedure describes how to install electrical interface assemblies
(EIAs). Typically, an EIA panel is installed on the backplane during
manufacturing, but EIA panels can be ordered separately. Refer to the
Cisco ONS 15454 Reference Manual for descriptions of the EIAs.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Perimeter screws (9)
Inner screws (12)
Backplane cover screws (5)
EIA card (SMB, BNC, AMP Champ, UBIC-V, UBIC-H, MiniBNC)
Prerequisite Procedures NTP-A4 Remove the Backplane Covers, page 1-7
Required/As Needed Required if the node will use electrical signals
