Cisco ONS 15454 Series User Manual

1-10
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A7 Install the Fan-Tray Assembly
Warning A readily accessible two-poled disconnect device must be incorporated in the fixed wiring. Statement
1022
Warning When installing redundant power feeds, do not use aluminum conductors.
Warning If you use redundant power leads to power the ONS 15454, disconnecting one lead will not remove
power from the node.
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Step 1 Verify one of the following:
• If you have the 15454-SA-ANSI or 15454-SA-HD shelf, a 100-A fuse panel (30-A fuse per shelf
minimum) should be installed. If not, install one according to manufacturer’s instructions.
• If you have the 15454-SA-NEBS3 shelf, a standard 80-A fuse panel (20-A fuse per shelf minimum)
should be installed. If not, install one according to manufacturer’s instructions.
Step 2 Complete the “DLP-A16 Connect the Office Ground to the ONS 15454” task on page 17-18.
Step 3 Complete the “DLP-A17 Connect Office Power to the ONS 15454 Shelf” task on page 17-19.
Step 4 Complete the “DLP-A18 Turn On and Verify Office Power” task on page 17-21.
Step 5 Continue with the “NTP-A7 Install the Fan-Tray Assembly” procedure on page 1-10.
Stop. You have completed this procedure.
NTP-A7 Install the Fan-Tray Assembly
Caution Do not operate an ONS 15454 without a fan-tray air filter. A fan-tray air filter is mandatory in order to
comply with Telcordia GR-78-CORE, except for applications in an outside plant cabinet.
Purpose This procedure installs the fan-tray assembly.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Prerequisite Procedures NTP-A3 Open and Remove the Front Door, page 1-6
NTP-A6 Install the Power and Ground, page 1-9
Required/As Needed Required
Onsite/Remote Onsite
Security Level None

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
