2-13
Cisco ONS 15454 Procedure Guide, R5.0
May 2006
Chapter 2 Install Cards and Fiber-Optic Cable
NTP-A316 Install the Filler Cards
• The ACT LED turns on green.
Note If the red FAIL LED does not turn on, check the power.
Note If you insert a card into a slot provisioned for a different card, all LEDs turn off.
Step 6 Complete the “DLP-A469 Install GBIC or SFP Connectors” task on page 21-24 to install GBICs on the
FC_MR-4 card.
Note If you need to remove a GBIC or SFP, complete the “DLP-A470 Remove GBIC or SFP
Connectors” task on page 21-26.
Step 7 Continue with the “NTP-A247 Install Fiber-Optic Cables on OC-N Cards” procedure on page 2-14.
Stop. You have completed this procedure.
NTP-A316 Install the Filler Cards
Warning
Blank faceplates (filler panels) serve three important functions: they prevent exposure to hazardous
voltages and currents inside the chassis; they contain electromagnetic interference (EMI) that might
disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not operate
the system unless all cards, power modules, and faceplates are in place.
Caution Always use the supplied electrostatic discharge (ESD) wristband when working with a powered ONS
15454. Plug the wristband cable into the ESD jack located on the lower right outside edge of the shelf
assembly and ensure the shelf assembly is properly grounded.
Purpose This procedure explains how to install the filler cards (blank faceplates) in
any unused traffic or AIC card slots (Slots 1 through 6, 9, and 11 through
17). The filler card aids in maintaining proper air flow and EMI
requirements.
Tools/Equipment Filler cards (Cisco P/N 15454-FILLER)
Prerequisite Procedures NTP-A15 Install the Common Control Cards, page 2-2
NTP-A16 Install the OC-N Cards, page 2-6
NTP-A17 Install the Electrical Cards, page 2-8
NTP-A246 Install Ethernet Cards and Connectors, page 2-10
NTP-A274 Install the FC_MR-4 Cards, page 2-11
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
