20-62
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A378 Provision Line DCC Terminations
Note DCC Termination Failure (EOC) and Loss of Signal (LOS) alarms appear until you create all
network DCC terminations and put the DCC termination OC-N ports in service.
Step 8 Return to your originating procedure (NTP).
DLP-A378 Provision Line DCC Terminations
Note When LDCC is provisioned, an SDCC termination is allowed on the same port, but is not recommended.
Using SDCC and LDCC on the same port is only needed during a software upgrade if the software
version does not support LDCC. You can provision SDCCs and LDCCs on different ports in the same
node.
Step 1 In node view, click the Provisioning > Comm Channels > LDCC tabs.
Step 2 Click Create.
Step 3 In the Create LDCC Terminations dialog box, click the ports where you want to create the LDCC
termination. To select more than one port, press the Shift key or the Ctrl key.
Note LDCC is used for ONS 15454 DCC terminations. The SONET LDCCs and the SDCC (when not
used as a DCC termination by the ONS 15454) can be provisioned as DCC tunnels. See the
“DLP-A313 Create a DCC Tunnel” task on page 20-7.
Step 4 In the Port Admin State area, click Set to IS to put the port in service.
Step 5 Verify that the Disable OSPF on DCC Link check box is unchecked.
Step 6 If the SDCC termination is to include a non-ONS node, check the Far End is Foreign check box. This
automatically sets the far-end node IP address to 0.0.0.0, which means that any address can be specified
by the far end. To change the default to a specific the IP address, see the “DLP-A375 Change a Line DCC
Termination” task on page 20-60.
Step 7 Click OK.
Purpose This task creates the LDCC terminations required for administration data,
alarms, signal control information, and messages. LDCCs are three times
larger than SDCCs. In this task, you can also set up the node so that it has
direct IP access to a far-end non-ONS node over the DCC network.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
