17-48
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A39 Install Ethernet Cards
Note If the red FAIL LED is on continuously or the LEDs act erratically, the card is not installed
properly. Remove the card and repeat Steps 1 to 5.
Step 6 Return to your originating procedure (NTP).
DLP-A39 Install Ethernet Cards
Step 1 Open the card latches/ejectors.
Step 2 Use the latches/ejectors to firmly slide the card along the guide rails until the card plugs into the
receptacle at the back of the slot.
Step 3 Verify that the card is inserted correctly and close the latches/ejectors on the card.
Note It is possible to close the latches/ejectors when the card is not completely plugged into the
backplane. Ensure that you cannot insert the card any further.
Step 4 Verify the LED activity:
For E-Series, G-Series and ML-Series cards:
• The red FAIL LED turns on for 20 to 30 seconds.
• The red FAIL LED blinks for 35 to 45 seconds.
• All LEDs blink once and turn off for 1 to 5 seconds.
• The ACT or ACT/STBY LED turns on. The SF LED can persist until all card ports connect to their
far end counterparts and a signal is present.
For CE-100T-8 card:
• The red FAIL LED blinks for 25 to 30 seconds and then turns off.
• The red FAIL LED blinks again for 55 to 60 seconds.
• All LEDs turn on for 1 to 5 seconds.
• The ACT LED turns on. The SF LED can persist until all card ports connect to their far end
counterparts and a signal is present.
Note If the red FAIL LED does not turn on, check the power.
Purpose This task installs the Ethernet cards (E100T-12, E100T-G, E1000-2,
E1000-2-G, G1000-4, G1K-4, ML100T-12, ML1000-2, and CE-100T-8).
Tools/Equipment Ethernet cards
Prerequisite Procedures NTP-A15 Install the Common Control Cards, page 2-2
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
