17-82
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A74 Create a New User on a Single Node
Figure 17-34 Creating a 1+1 Protection Group
Step 5 From the Available Ports list, choose the port that will be protected by the port you selected in the
Protect Port field. Click the top arrow button to move each port to the Working Ports list.
Step 6 Complete the remaining fields:
• Bidirectional switching—Check this check box if you want both Tx and Rx signals to switch to the
protect port when a failure occurs to one signal. Leave unchecked if you want only the failed signal
to switch to the protect port.
• Revertive—Check this check box if you want traffic to revert to the working card after failure
conditions remain corrected for the amount of time entered in the Reversion Time field.
• Reversion time—If Revertive is checked, choose a reversion time from the drop-down list. The
range is 0.5 to 12.0 minutes. The default is 5.0 minutes. Reversion time is the amount of time that
will elapse before the traffic reverts to the working card after conditions causing the switch are
cleared. The reversion timer starts after conditions causing the switch are cleared.
Step 7 Click OK.
Step 8 Return to your originating procedure (NTP).
DLP-A74 Create a New User on a Single Node
Step 1 In node view, click the Provisioning > Security > Users tabs.
Step 2 In the Users window, click Create.
Step 3 In the Create User dialog box, enter the following:
Purpose This task creates a new user for one ONS 15454.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
