DLP-A412 Install the DCU Shelf Assembly
Step 1 The DCU chassis requires 1 rack unit (RU) in a standard 19-inch (482.6-mm) or 23-inch (584.2-mm)
rack. Locate the RMU space specified in your site plan.
Step 2 Two sets of mounting brackets are included with the DCU mounting kit, one set each for 19-inch
(482.6-mm) and 23-inch (584.2-mm) racks. Verify that your chassis is equipped with the correct set of
brackets for your rack. Change the brackets as required.
Step 3 Align the chassis with the rack mounting screw holes; one at a time, insert and tighten the four screws.
Warning
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection
authority or an electrician if you are uncertain that suitable grounding is available.
Statement 1024
Step 4 Connect a frame ground to the ground terminal provided on either side of the chassis. Use minimum
#14 AWG wire.
Purpose If you are installing dispersion compensation modules, use this task to
install the dispersion compensation unit (DCU) chassis.
Tools/Equipment #2 Phillips screwdriver
Crimping tool
#14 AWG wire and lug
Prerequisite Procedures None
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
