Cisco ONS 15454 Series User Manual

20-36
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A350 View FC_MR-4 Statistics PM Parameters
Caution Pressing the Clear button can mask problems if used incorrectly. This button is commonly used for
testing purposes. After pressing this button, the current bin is marked invalid. Also note that the
unavailable seconds (UAS) state is not cleared if you were counting UAS; therefore, this count could be
unreliable when UAS is no longer counting.
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 Click Clear.
Step 4 From the Clear Statistics drop-down list, choose one of these three options:
• Displayed statistics: Clearing displayed statistics erases from the card and the window all PM
counts associated with the current combination of statistics on the selected port. This means the
selected time interval, direction, and signal type counts are erased from the card and the window.
• All statistics for port x: Clearing all statistics for port x erases from the card and the window all
PM counts associated with all combinations of the statistics on the selected port. This means all time
intervals, directions, and signal type counts are erased from the card and the window.
• All statistics for card: Clearing all statistics for card erases from the card and the window all PM
counts for all ports.
Step 5 From the Clear Statistics drop-down list, choose OK to clear the selected statistics.
Step 6 Verify that the selected PM counts have been cleared.
Step 7 Return to your originating procedure (NTP).
DLP-A350 View FC_MR-4 Statistics PM Parameters
Step 1 In node view, double-click the FC_MR-4 card where you want to view PM counts. The card view
appears.
Step 2 Click the Performance > Statistics tabs (Figure 20-6).
Purpose This task enables you to view current statistical PM counts on an
FC_MR-4 card and port to detect possible performance problems.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
