1-21
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A9 Install the Electrical Card Cables on the Backplane
NTP-A9 Install the Electrical Card Cables on the Backplane
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Note Refer to the Cisco ONS 15454 Reference Manual for more information about EIAs.
Step 1 Complete the “DLP-A530 Install the Tie-Down Bar” task on page 22-27 as needed for routing the
electrical cables you will install.
Step 2 Complete the “DLP-A23 Install DS-1 Cables Using Electrical Interface Adapters (Balun)” task on
page 17-28 as needed. Baluns are used on SMB EIAs to properly terminate DS-1 signals.
Step 3 To install DS-1 cables using AMP Champ cables, complete the “DLP-A24 Install DS-1 AMP Champ
Cables on the AMP Champ EIA” task on page 17-29.
Step 4 Complete the “DLP-A25 Install Coaxial Cable With BNC Connectors” task on page 17-32 as needed.
Step 5 Complete the “DLP-A26 Install Coaxial Cable With High-Density BNC Connectors” task on page 17-33
as needed.
Step 6 Complete the “DLP-A27 Install Coaxial Cable with SMB Connectors” task on page 17-33 as needed.
Step 7 Complete the “DLP-A386 Install Electrical Cables on the UBIC-V EIAs” task on page 20-70 as needed.
Step 8 Complete the “DLP-A441 Install Electrical Cables on the UBIC-H EIAs” task on page 21-21 as needed.
Step 9 Continue with the “NTP-A10 Route Electrical Cables” procedure on page 1-22.
Stop. You have completed this procedure.
Purpose Optional EIA backplane covers are typically preinstalled when ordered
with the ONS 15454. The following procedure describes how to install the
electrical card cables to the backplane. If the shelf was not shipped with the
correct EIA interface, you must order and install the correct EIA.
Tools/Equipment Wire wrapper
Twisted-pair cables
BNC insertion tool
SMB cable connector
#2 Phillips screwdriver
Medium slot-head screwdriver
DS-1 and DS-3 cables, as needed
Tie-down bar, as needed
Prerequisite Procedures NTP-A5 Install the EIAs, page 1-7
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
