2-2
Cisco ONS 15454 Procedure Guide, R5.0
May 2006
Chapter 2 Install Cards and Fiber-Optic Cable
NTP-A15 Install the Common Control Cards
Warning
Blank faceplates and cover panels serve three important functions: they prevent exposure to
hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI)
that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not
operate the system unless all cards, faceplates, front covers, and rear covers are in place.
Statement
1029
NTP-A15 Install the Common Control Cards
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
Statement 94
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Note If protective clips are installed on the backplane connectors of the cards, remove the clips before
installing the cards.
Note If you install a card incorrectly, the FAIL LED flashes continuously.
Step 1 If you plan to install XCVT cards, review Table 2-1 to determine card/slot compatibility. If you plan to
install XC10G cards, review Table 2-2 on page 2-5 to determine card/slot compatibility.
Step 2 Complete the “DLP-A36 Install the TCC2/TCC2P Cards” task on page 17-42.
Step 3 Complete the “DLP-A37 Install the XCVT or XC10G Cards” task on page 17-45.
Step 4 Complete the “DLP-A38 Install the Alarm Interface Controller or Alarm Interface
Controller–International Card” task on page 17-47, as needed.
Note If you install the wrong card in a slot, see the “NTP-A116 Remove and Replace a Card”
procedure on page 2-17.
Purpose This procedure describes how to install the common control cards.
Tools/Equipment Redundant TCC2/TCC2P cards
Redundant XCVT or XC10G (cross-connect) cards
AIC/AIC-I card (optional)
Prerequisite Procedures NTP-A13 Perform the Shelf Installation Acceptance Test, page 1-30
Required/As Needed Required
Onsite/Remote Onsite
Security Level Provisioning or higher
