CHAPTER
1-1
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
1
Install the Shelf and Backplane Cable
This chapter provides procedures for installing the Cisco ONS 15454. For a summary of the tools and
equipment required for installation, see the “Required Tools and Equipment” section on page 1-2.
Before You Begin
This section lists the chapter procedures (NTPs). Turn to a procedure for applicable tasks (DLPs).
1. NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly, page 1-4—Complete this procedure
before continuing with the “NTP-A2 Install the Shelf Assembly” procedure on page 1-5.
2. NTP-A2 Install the Shelf Assembly, page 1-5—Complete this procedure to install the shelf
assembly in a rack.
3. NTP-A3 Open and Remove the Front Door, page 1-6—Complete this procedure to access the
equipment before continuing with other procedures.
4. NTP-A4 Remove the Backplane Covers, page 1-7—Complete this procedure to access the
backplane before continuing with other procedures.
5. NTP-A5 Install the EIAs, page 1-7—Complete this procedure if you plan to install electrical cards.
This procedure is a prerequisite to the “NTP-A9 Install the Electrical Card Cables on the Backplane”
procedure on page 1-21.
6. NTP-A6 Install the Power and Ground, page 1-9—Complete this procedure before continuing with
the “NTP-A7 Install the Fan-Tray Assembly” procedure on page 1-10.
7. NTP-A7 Install the Fan-Tray Assembly, page 1-10—Complete this procedure to install the fan-tray
assembly in the shelf.
8. NTP-A119 Install the Alarm Expansion Panel, page 1-12—Complete this procedure if you are
planning to install the Alarm Interface Controller–International (AIC-I) card and want to increase
the number of alarm contacts provided by the AIC-I card.
9. NTP-A8 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections, page 1-15—Complete
this procedure as needed to set up wire-wrap pin connections.
10. NTP-A120 Install an External Wire-Wrap Panel to the AEP, page 1-16—Complete this procedure to
connect an external wire-wrap panel to the alarm expansion panel (AEP).
11. NTP-A9 Install the Electrical Card Cables on the Backplane, page 1-21—Complete this procedure
if you plan to install electrical card cables.
12. NTP-A10 Route Electrical Cables, page 1-22—Complete this procedure as needed before
continuing with the “NTP-A11 Install the Rear Cover” procedure on page 1-22.
