21-24
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 21 DLPs A400 to A499
DLP-A469 Install GBIC or SFP Connectors
DLP-A469 Install GBIC or SFP Connectors
Note G-Series cards manufactured before August 2003 do not support DWDM GBICs. G1000-4 cards
compatible with DWDM GBICs have a Common Language Equipment Identification (CLEI) code of
SNP8KW0KAB. Compatible G1K-4 cards have a CLEI code of WM5IRWPCAA.
Note All versions of G1000-4 and G1K-4 cards support coarse wavelength division multiplexing (CWDM)
GBICs.
Note GBICs and SFPs are hot-swappable and can therefore be installed/removed while the card/shelf
assembly is powered and running.
Purpose This task installs GBICs (required for E-Series Ethernet, G-Series Ethernet,
and FC_MR-4 cards) and Small Form-factor Pluggables (SFPs) (required
for ML1000-2 and MXP cards). SFPs are hot-swappable input/output
devices that plug into a line card port to link the port with the fiber-optic
network. For a description of SFP connectors on transponder or muxponder
cards, refer to the Cisco ONS 15454 DWDM Installation and Operations
Guide.
Tools/Equipment For the E1000-2-G use:
• SX GBIC= for short-reach applications
• LX GBIC= for long-reach applications
For the G1000-4 or G1K-4 card use:
• SX GBIC= for short-reach applications
• LX GBIC= for long-reach applications
• ZX GBIC= for extra long-reach applications
• DWDM GBIC= for DWDM applications
For the ML1000-2 card use:
• SX SFP= for short-reach applications
• LX SFP= for long-reach applications
For the FC_MR-4 card use:
• ONS-GX-2FC-SML= for 2-Gb FC 1310-nm single-mode with SC
connectors
• ONS-GX-2FC-MMI= for 2-Gb FC 850-nm multimode with SC
connectors
Prerequisite Procedures DLP-A39 Install Ethernet Cards, page 17-48
NTP-A274 Install the FC_MR-4 Cards, page 2-11
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
