20-33
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A347 Refresh E-Series and G-Series Ethernet PM Counts
Step 11 Return to your originating procedure (NTP).
DLP-A347 Refresh E-Series and G-Series Ethernet PM Counts
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance > History tabs.
Step 3 From the Interval drop-down list, click one of the following:
• 1 min
• 15 min
• 1 hour
• 1 day
Step 4 Click Refresh. Performance monitoring appears in the interval selected, synchronized with the time of
day.
Step 5 View the Prev column to find PM counts for the latest selected interval.
Each monitored performance parameter has corresponding threshold values for the latest time period. If
the value of the counter exceeds the threshold value for a particular selected interval, a threshold crossing
alert (TCA) is raised. The number represents the counter value for each specific performance monitoring
parameter.
Step 6 View the Prev-n columns to find PM counts for the previous intervals.
Note If a complete count over the selected interval is not possible, the value appears with a yellow
background. For example, if you selected the 1-day interval, an incomplete or incorrect count
can be caused by changing node timing settings, changing the time zone settings, monitoring for
less than 24 hours after the counter started, replacing a card, resetting a card, or changing port
service states. When the problem is corrected, the subsequent 1-day interval appears with a white
background.
Step 7 Return to your originating procedure (NTP).
Purpose This task changes the window view to display E-Series and G-Series
Ethernet PM parameters intervals.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
