Chapter 19 DLPs A200 to A299
DLP-A264 Provision a J1 Path Trace on Circuit Source and Destination Ports
Note For FC_MR-4 cards, the path trace string must be identical for all members of the VCAT circuit.
You cannot mix path trace strings across members of a VCAT group. When retrieving the path
trace string on the FC_MR-4 card view Maintenance > Path Trace subtab, only the member
assigned a path trace string displays the path trace information.
Note If neither port is on a transmit/receive card, you will not be able to complete this procedure. If
one port is on a transmit/receive card and the other is on a receive-only card, you can set up the
transmit string at the transmit/receive port and the receive string at the receive-only port, but you
will not be able to transmit in both directions.
Step 4 Choose the STS circuit you want to trace, then click Edit.
Step 5 If you chose a VCAT circuit, complete the following. If not, continue with Step 6.
a. In the Edit Circuit window, click the Members tab.
Table 19-3 Path-Trace-Capable ONS 15454 Cards
J1 Function Cards
Transmit and Receive DS1-14
1
DS1N-14
DS3-12E
DS3N-12E
DS3XM-6
DS3XM-12
DS3i-N-12
DS3/EC1-48
G1000-4
1. J1 path trace is not supported for DS-1s used in VT circuits.
Receive Only EC1-12
OC3 IR 4/STM1 SH 1310
OC3 IR 4/STM1 SH 1310-8
OC12/STM4-4
OC48 IR/STM16 SH AS 1310
OC48 LR/STM16 LH AS 1550
OC192 SR/STM64 IO 1310
OC192 LR/STM64 LH 1550
OC192 IR/STM SH 1550
ML100T-12
ML1000-2
FC_MR-4
