Cisco ONS 15454 Series User Manual

21-26
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 21 DLPs A400 to A499
DLP-A470 Remove GBIC or SFP Connectors
c. When you are ready to attach the network fiber-optic cable, remove the protective plug from the
GBIC and save the plug for future use.
d. Continue with Step 7.
Step 5 For GBICs with a handle:
a. Remove the protective plug from the SC-type connector.
b. Grip the sides of the GBIC with your thumb and forefinger and insert the GBIC into the slot on the
card.
c. Lock the GBIC into place by closing the handle down. The handle is in the correct closed position
when it does not obstruct access to an SC-type connector.
d. Slide the GBIC through the cover flap until you hear a click.
The click indicates that the GBIC is locked into the slot.
e. Continue with Step 7.
Warning Class 1 laser product. Statement 1008
Warning Invisible laser radiation could be emitted from the end of the unterminated fiber cable or connector.
Do not stare into the beam directly with optical instruments. Viewing the laser output with certain
optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of
100 mm could pose an eye hazard. Statement 1056
Step 6 For SFPs:
a. Plug the LC duplex connector of the fiber into a Cisco-supported SFP connector.
b. If the new SFP connector has a latch, close the latch over the cable to secure it.
c. Plug the cabled SFP connector into the card port until it clicks.
Step 7 Return to your originating procedure (NTP).
DLP-A470 Remove GBIC or SFP Connectors
Warning Invisible laser radiation could be emitted from the end of the unterminated fiber cable or connector.
Do not stare into the beam directly with optical instruments. Viewing the laser output with certain
optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of
100 mm could pose an eye hazard. Statement 1056
Purpose This task disconnects fiber attached to GBICs or SFPs and removes the
GBICs or SFPs.
Tools/Equipment None
Prerequisite Procedures DLP-A469 Install GBIC or SFP Connectors, page 21-24
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
