18-31
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A165 Change Line and Threshold Settings for the DS1-14 or DS1N-14 Cards
Table 18-5 describes the values on the Provisioning > Elect Path Thresholds tabs for the DS-1 cards.
Table 18-6 describes the values on the Provisioning > SONET Thresholds tabs for the DS-1 cards.
Table 18-5 Electrical Path Threshold Options for DS1-14 and DS1N-14 Cards
Parameter Description Options
Port (Display only.) Port number 1 to 14
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
SAS Severely errored frame/alarm indication
signal
Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
AISS Alarm indication signal seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
Table 18-6 SONET Threshold Options for DS1-14 and DS1N-14 Cards
Parameter Description Options
Port (Display only.) DS-1 ports partitioned for
STS
Line 1, STS 1, Line 2, STS 1
Line 3, STS 1, Line 4 STS 1
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near End, STS
termination).
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near End, STS
termination).
FC Failure count Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near End, STS
termination).
