22-25
Cisco ONS 15454 Procedure Guide, R5.0
October 2005
Chapter 22 DLPs A500 to A599
DLP-A528 Change the Default Network View Background Map
Note The threshold value appears after the circuit is created.
Step 7 Return to your originating procedure (NTP).
DLP-A528 Change the Default Network View Background Map
Note If you modify the background image, the change is stored in your CTC user profile on the computer. The
change does not affect other CTC users.
Step 1 From the Edit menu, choose Preferences > Map and check the Use Default Map check box.
Step 2 In the node view, click the Provisioning > Defaults tabs.
Step 3 In the Defaults Selector area, choose CTC and then network.
Step 4 Choose a default map from the Default Value drop-down list. Map choices are: Germany, Japan,
Netherlands, South Korea, United Kingdom, and United States (default).
Table 22-4 SONET Threshold Options for DS3i-N-12 Cards
Parameter Description Options
Port (Display only.) Port number 1 to 12
CV Coding violations Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click the Show
Thresholds button.
ES Errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds.
FC Failure count Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(STS and VT Term).
SES Severely errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(Near and Far End, Sts Term or Vt Term).
UAS Unavailable seconds Numeric. Can be set for 15-minute or one-day intervals
for Line or Path (Near and Far End). Select the bullet
and click Show Thresholds.
Purpose This task changes the default map of the CTC network view.
Tools/Equipment None
Prerequisite procedures DLP-A60 Log into CTC, page 17-66
Required/As needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
