DLP-A526 Change Line and Threshold Settings for the DS3i-N-12 Cards
Step 3 Depending on the setting you need to modify, click the Line, Line Thresholds, Elect Path Thresholds,
or SONET Thresholds subtab.
Note See Chapter 7, “Manage Alarms” for information about the Alarm Behavior tab.
Step 4 Modify any of the settings found under these subtabs. For definitions of the line settings, see Table 22-1.
For definitions of the line threshold settings, see Table 22-2. For definitions of the electrical path
threshold settings, see Table 22-3. For definitions of the SONET threshold settings, see Table 22-4.
Step 5 Click Apply.
Step 6 Repeat Steps 3 through 5 for each subtab that has parameters you want to provision.
Table 22-1 describes the values on the Provisioning > Line tabs for the DS3i-N-12 cards.
Table 22-1 Line Options for the DS3i-N-12 Cards
Parameter Description Options
Port # (Display only.) Shows the
port number.
1 to 12
Port Name Sets the port name. User-defined, up to 32 alphanumeric/ special characters.
Blank by default.
See the “DLP-A314 Assign a Name to a Port” task on
page 20-8.
SF BER Sets the signal fail bit error
rate.
• 1E-3
• 1E-4
• 1E-5
SD BER Sets the signal degrade bit
error rate.
• 1E-5
• 1E-6
• 1E-7
• 1E-8
• 1E-9
Line Type Defines the line framing
type.
• Unframed
• M13
• C Bit
• Auto Provisioned
Detected
Line Type
(Display only.) Displays
the detected line type.
• M13
• C Bit
• Unframed
• Unknown
Line
Coding
(Display only.) Defines the
DS3E transmission coding
type.
B3ZS
