19-21
Cisco ONS 15454 Procedure Guide, R5.0
September 2005
Chapter 19 DLPs A200 to A299
DLP-A232 Change Active and Standby Span Color
DLP-A232 Change Active and Standby Span Color
Step 1 From the Edit menu in any view, choose Preferences.
Step 2 In the Preferences dialog box, click the Circuit tab.
Step 3 Complete one or more of the following steps, as required:
• To change the color of the active (working) span, go to Step 4.
• To change the color of the standby (protect) span, go to Step 5.
• To return active and standby spans to their default colors, go to Step 6.
Step 4 As needed, change the color of the active span:
a. In the Span Colors area, click the colored square near the word Active.
b. In the Pick a Color dialog box, click the color for the active span, or click the Reset button if you
want the active span to display the last applied (saved) color.
c. Click OK to close the Pick a Color dialog box. If you want to change the standby span color, go to
Step 5. If not, click OK to save the change and close the Preferences dialog box, or click Apply to
save the change and keep the Preferences dialog box open.
Step 5 As needed, change the color of the standby span:
a. In the Span Colors area, click the colored square near the word Standby.
b. In the Pick a Color dialog box, click the color for the standby span, or click the Reset button if you
want the standby span to display the last applied (saved) color.
c. Click OK to save the change and close the Preferences dialog box, or click Apply to save the change
and keep the Preferences dialog box open.
Step 6 As needed, return the active and standby spans to their default colors:
a. From the Edit menu, choose Preferences.
b. In the Preferences dialog box, click the Circuits tab.
c. Click Reset to Defaults.
d. Click OK to save the change and close the Preferences dialog box, or click Apply to save the change
and keep the Preferences dialog box open.
Step 7 Return to your originating procedure (NTP).
Purpose This task changes the color of active (working) and standby (protect)
circuit spans shown on the detailed circuit map of the Edit Circuits
window. By default, working spans are green and protect spans are purple.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
