11-3
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 11 Change Card Settings
NTP-A90 Modify Alarm Interface Controller Settings
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to change the
OC-N card settings. If you are already logged in, proceed to Step 2.
Step 2 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Step 3 Perform any of the following tasks as needed:
DLP-A170 Change Line Transmission Settings for OC-N Cards, page 18-49
DLP-A171 Change Threshold Settings for OC-N Cards, page 18-51
DLP-A172 Change an Optical Port to SDH, page 18-53
Step 4 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Stop. You have completed this procedure.
NTP-A90 Modify Alarm Interface Controller Settings
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to change the
AIC card settings. If you are already logged in, proceed to Step 2.
Step 2 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Step 3 Perform any of the following tasks as needed:
DLP-A173 Change External Alarms Using the AIC Card, page 18-54
DLP-A174 Change External Controls Using the AIC Card, page 18-54
DLP-A175 Change Orderwire Settings Using the AIC Card, page 18-55
Step 4 Complete the “NTP-A108 Back Up the Database” procedure on page 15-4.
Stop. You have completed this procedure.
Purpose This procedure provisions the AIC card to receive input from, or send
output to, external devices wired to the backplane (called external alarms
and controls or environmental alarms) and changes orderwire settings.
Tools/Equipment None
Prerequisite Procedures NTP-A32 Provision External Alarms and Controls on the Alarm Interface
Controller, page 7-9
DLP-A83 Provision Orderwire, page 17-84
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
