Cisco ONS 15454 Series User Manual

20-91
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A394 View DS-N/SONET PM Parameters for the DS3XM-12 Card
Note To refresh, reset, or clear PM counts, see the “NTP-A253 Change the PM Display” procedure
on page 8-2.
Step 5 Return to your originating procedure (NTP).
DLP-A394 View DS-N/SONET PM Parameters for the DS3XM-12 Card
Step 1 In node view, double-click the DS3XM-12 electric card where you want to view PM counts. The card
view appears.
Step 2 Click the Performance > DSn/SONET PM tabs to view the DS-N/SONET Performance parameters
(Figure 20-21).
Purpose This task enables you to view DS-N/SONET PM parameters for
near-end or far-end performance during selected time intervals on an
DS3XM-12 electrical card and port to detect possible performance
problems.
Tools/Equipment None
Prerequisite Procedures Before you monitor performance, be sure you have created the
appropriate circuits and provisioned the card according to your
specifications. For more information, see Chapter 6, “Create Circuits
and VT Tunnels” and Chapter 11, “Change Card Settings.”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
