20-5
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A310 View Ethernet Trunk Utilization
DLP-A310 View Ethernet Trunk Utilization
Step 1 In node view, click the Maintenance > Ether Bridge > Trunk Utilization tabs.
Step 2 Select the desired time interval in the Interval field.
Step 3 Click Refresh.
The trunk utilization information for the current and previous time intervals is displayed.
Step 4 Return to your originating procedure (NTP).
DLP-A311 Provision a Half Circuit Source and Destination on a BLSR or 1+1
Step 1 From the Node drop-down list, choose the node that will contain the half circuit.
Step 2 From the Slot drop-down list, choose the slot containing the card where the circuit will originate.
Step 3 From the Port drop-down list, choose the port where the circuit will originate. This field is not available
if a DS-1 card is chosen in Step 2.
Step 4 If the circuit is a DS-1 circuit and you choose a DS-1 card as the source, choose the DS-1 where the
traffic will originate from the DS1 drop-down list.
Step 5 Click Next.
Step 6 From the Node drop-down list, choose the node chosen in Step 1.
Step 7 From the Slot drop-down list, choose the OC-N card that you will use to map the DS-1 to a VT1.5 for
OC-N transport or to map the DS-3 or OC-N synchronous transport signal (STS) circuit to an STS.
Purpose This task displays the Ethernet Trunk bandwidth usage on any node with
one or more E-Series Ethernet cards installed.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This task provisions a half circuit source and destination for BLSR and 1+1
configurations. A half circuit allows you to provision a partial path (one
end of a circuit), for example, if you want to provision a circuit with the
intent that the path will be completed at a later time or at a different
location.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
