9-2
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 9 Manage Circuits
NTP-A199 Locate and View Circuits
NTP-A199 Locate and View Circuits
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at a node on the network where you want
to view the circuits. If you are already logged in, continue with Step 2.
Note Do not check Disable Circuit Management in the Login dialog box. No circuits appear if this
option is checked.
Step 2 As needed, complete the “DLP-A416 View Circuit Information” task on page 21-2.
Step 3 As needed, complete the “DLP-A131 Search for Circuits” task on page 18-14.
Step 4 As needed, complete the “DLP-A262 Filter the Display of Circuits” task on page 19-44.
Step 5 As needed, complete the “DLP-A229 View Circuits on a Span” task on page 19-18.
Step 6 As needed, complete the “DLP-A417 View the BLSR Squelch Table” task on page 21-5.
Step 7 As needed, complete the “DLP-A430 View Spanning Tree Information” task on page 21-9.
Stop. You have completed this procedure.
NTP-A200 View Cross-Connect Card Resource Usage
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you want to view the
cross-connect card resource usage. If you are already logged in, continue with Step 2.
Step 2 Click the Maintenance > Cross-Connect > Resource Usage tabs.
Purpose This procedure allows you to locate and view circuits and spanning tree
information.
Tools/Equipment None
Prerequisite Procedures Circuit creation procedure(s) in Chapter 6, “Create Circuits and VT
Tunnels”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This procedure allows you to view the percentage of cross-connect card
resources used by circuits that traverse or terminate at an ONS 15454.
Tools/Equipment XCVT or XC10G cards must be installed.
Prerequisite Procedures DLP-A37 Install the XCVT or XC10G Cards, page 17-45
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
