5-31
Cisco ONS 15454 Procedure Guide, R5.0
December 2004
Chapter 5 Turn Up Network
NTP-A224 Provision an Open-Ended Path Protection
Figure 5-10 Integrated BLSR to Path Protection DRI Example
Stop. You have completed this procedure.
NTP-A224 Provision an Open-Ended Path Protection
Node 1
West WestEast
WestEast
East
West East
BLSR Ring
Ring
Node 4
Node 2
Node 3
Slot 5
Slot 12
Tx
Rx
Slot 2Slot 1
Slot 5
Tx
Rx
Slot 12
Slot 5
Slot 12
Tx
Rx
Slot 1
Tx
Rx
Slot 2
Slot 5 Slot 12
Node 1 Node 2
Slot 5
Slot 12
Tx
Rx
Tx
Rx
Tx
Rx
Slot 5
Slot 12
Tx
Rx
Tx
Rx
Tx
Rx
115274
Purpose This procedure provisions ONS 15454s in an open-ended path protection
connected to a third-party vendor network. This topology allows you to
route a circuit from one ONS 15454 network to another ONS 15454
network through the third-party network.
Tools/Equipment None
Prerequisite Procedures NTP-A35 Verify Node Turn-Up, page 5-2
Required/As Needed As needed
Onsite/Remote Onsite
Security Level Provisioning and higher
