18-13
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A127 View Far-End PM Counts
DLP-A127 View Far-End PM Counts
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 Click the Far End radio button.
Step 4 Click Refresh. All PM parameters recorded by the far-end node for the selected card on the outgoing
signal appear. For PM parameter definitions, refer to the “Performance Monitoring” chapter of the
Cisco ONS 15454 Troubleshooting Guide.
Step 5 View the Curr column to find PM counts for the current time interval.
Step 6 View the Prev-n columns to find PM counts for the previous time intervals.
Step 7 Return to your originating procedure (NTP).
DLP-A129 Reset Current PM Counts
Step 1 In node view, double-click the card where you want to view PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 Click Baseline.
Note The Baseline button clears the PM counts displayed in the current time interval but does not clear
the PM counts on the card. When the current time interval expires or the window view changes,
the total number of PM counts on the card and on the window appear in the appropriate column.
The baseline values are discarded if you change views to a different window and then return to
the Performance window.
Purpose This task enables you to view far-end PM parameters for the selected
card and port.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This task clears the current PM count, but it does not clear the
cumulative PM count. This task allows you to see how quickly PM
counts rise.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
