Chapter 20 DLPs A300 to A399
DLP-A399 Install a UBIC-H EIA
Figure 20-23 Installed Alignment Standoffs
Step 6
Line up the alignment pins on the UBIC-H EIA (Figure 20-24) with the alignment standoffs on the
shelf and push the UBIC-H EIA with consistent pressure until the pins and standoffs fit together firmly.
Installed alignment standoffs
120366
