Cisco ONS 15454 Series User Manual

18-44
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A168 Change Line and Threshold Settings for the DS3XM-6 Card
Table 18-18 describes the values on the Provisioning > SONET Thresholds tabs for the DS3XM-6 cards.
Table 18-17 Electrical Path Threshold Options for the DS3XM-6 Card
Parameter Description Options
Port (Display only.) Port number 1 to 6
CV Coding violations Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
ES Errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
SES Severely errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
SAS Severely errored frame/alarm
indication signal
Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
AISS Alarm indication signal
seconds
Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
UAS Unavailable seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click Show Thresholds
(DS3, Pbit Near End only; DS3 CPbit, Near and Far
End; DS1, only if there is a VT circuit dropped on the
port).
Table 18-18 SONET Threshold Options for the DS3XM-6 Card
Parameter Description Options
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (STS and VT Term).
