20-61
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A377 Provision Section DCC Terminations
• Far End is Foreign—Check this box to specify that the LDCC termination is a non-ONS node.
• Far end IP—If you checked the Far End is Foreign check box, type the IP address of the far-end node
or leave the 0.0.0.0 default. An IP address of 0.0.0.0 means that any address can be used by the far
end.
Step 5 Click OK.
Step 6 Return to your origination procedure (NTP).
DLP-A377 Provision Section DCC Terminations
Note When SDCC is provisioned, an LDCC termination is allowed on the same port, but is not recommended.
Using SDCC and LDCC on the same port is only needed during a software upgrade if the software
version does not support LDCC. You can provision SDCCs and LDCCs on different ports in the same
node.
Step 1 In node view, click the Provisioning > Comm Channels > SDCC tabs.
Step 2 Click Create.
Step 3 In the Create SDCC Terminations dialog box, click the ports where you want to create the SDCC
termination. To select more than one port, press the Shift key or the Ctrl key.
Note SDCC is used for ONS 15454 DCC terminations. The SONET LDCCs and the SDCC (when not
used as a DCC termination by the ONS 15454) can be provisioned as DCC tunnels. See the
“DLP-A313 Create a DCC Tunnel” task on page 20-7.
Step 4 In the Port Admin State area, click Set to IS to put the port in service.
Step 5 Verify that the Disable OSPF on SDCC Link check box is unchecked.
Step 6 If the SDCC termination is to include a non-ONS node, check the Far End is Foreign check box. This
automatically sets the far-end node IP address to 0.0.0.0, which means that any address can be specified
by the far end. To change the default to a specific IP address, see the “DLP-A374 Change a Section DCC
Termination” task on page 20-60.
Step 7 Click OK.
Purpose This task creates the SONET SDCC terminations required for alarms,
administration data, signal control information, and messages. In this task,
you can also set up the node so that it has direct IP access to a far-end
non-ONS node over the DCC network.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
