Cisco ONS 15454 Series User Manual

17-52
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A44 Install Fiber-Optic Cables for BLSR Configurations
Figure 17-22 Connecting Fiber to a Six-Node Integrated Path Protection Dual-Ring Interconnect
Step 4
Return to your originating procedure (NTP).
DLP-A44 Install Fiber-Optic Cables for BLSR Configurations
Purpose This task installs the fiber-optics to the east and west bidirectional line
switched ring (BLSR) ports at each node. See Chapter 5, “Turn Up
Network” to provision and test BLSR configurations.
Tools/Equipment Fiber-optic cables
Prerequisite Procedures NTP-A112 Clean Fiber Connectors, page 15-13
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
Node 1
Node 3
Node 2
Node 4
Slot
5
Slot
12
Tx
Rx
Slot
5
Slot
12
Tx
Rx
Slot
6
Slot
13
Slot
5
Slot
12
Tx
Rx
Slot
5
Slot
12
Tx
Rx
Slot
6
Slot
13
Node 5 Node 6
Slot
5
Slot
12
Tx
Rx
Slot
5
Slot
12
Tx
Rx
83500

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
