20-83
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 20 DLPs A300 to A399
DLP-A388 Change Line and Threshold Settings for the DS3/EC1-48 Cards
Table 20-9 describes the values on the Provisioning > Line Thresholds tabs for the DS3/EC1-48 card.
Table 20-10 describes the values on the Provisioning > Elect Path Thresholds tabs for the DS3/EC1-48
card.
Line Length Defines the distance (in feet) from
backplane connection to the next
termination point.
• 0 - 225 (default)
• 226 - 450
AINS Soak Sets the automatic in-service soak period. Duration of valid input signal, in hh.mm
format, after which the card becomes in
service (IS) automatically 0 to 48 hours,
15-minute increments
Table 20-8 Line Options for the DS3/EC1-48Card (continued)
Parameter Description Options
Table 20-9 Line Threshold Options for DS3/EC1-48 Card
Parameter Description Options
Port Port number 1 to 48 (read-only)
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
LOSS Loss of signal seconds; number of
one-second intervals containing one or
more LOS defects
Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds.
Table 20-10 Electrical Path Threshold Options for the DS3/EC1-48 Card
Parameter Description Options
Port (Display only.) Port number 1 to 48
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (Pbit Near End only;
CPbit, Near and Far End).
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and click
Show Thresholds (Pbit Near End only;
CPbit, Near and Far End).
