Chapter 20 DLPs A300 to A399
DLP-A388 Change Line and Threshold Settings for the DS3/EC1-48 Cards
Service
State
Identifies the autonomously generated
state that gives the overall condition of
the port. Service states appear in the
format: Primary State-Primary State
Qualifier, Secondary State.
• IS-NR—(In-Service and Normal) The
port is fully operational and performing
as provisioned.
• OOS-AU,AINS—(Out-Of-Service and
Autonomous, Automatic In-Service)
The port is out-of-service, but traffic is
carried. Alarm reporting is suppressed.
The ONS node monitors the ports for an
error-free signal. After an error-free
signal is detected, the port stays in
OOS-AU,AINS state for the duration of
the soak period. After the soak period
ends, the port service state changes to
IS-NR.
• OOS-MA,DSBLD—(Out-of-Service
and Management, Disabled) The port is
out-of-service and unable to carry
traffic.
• OOS-MA,MT—(Out-of-Service and
Management, Maintenance) The port is
out-of-service for maintenance. Alarm
reporting is suppressed, but traffic is
carried and loopbacks are allowed.
SF BER Sets the signal fail bit error rate.
• 1E-3
• 1E-4
• 1E-5
SD BER Sets the signal degrade bit error rate.
• 1E-5
• 1E-6
• 1E-7
• 1E-8
• 1E-9
Line Type Defines the line framing type.
• Unframed - default
• M13
• C BIT
• Auto Provision Fmt
Detected
Line Type
(Display only.) Displays the detected line
type.
• M13
• C Bit
• Unframed
• Unknown
Line Coding Defines the DS-3 transmission coding
type that is used.
B3ZS
Table 20-8 Line Options for the DS3/EC1-48Card (continued)
Parameter Description Options
