17-47
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A38 Install the Alarm Interface Controller or Alarm Interface Controller–International Card
DLP-A38 Install the Alarm Interface Controller or Alarm Interface
Controller–International Card
Note When installing cards, allow each card to boot completely before installing the next card.
Step 1 Open the latches/ejectors on the card.
Step 2 Use the latches/ejectors to firmly slide the card along the guide rails until the card plugs into the
receptacle at the back of the slot (Slot 9).
Step 3 Verify that the card is inserted correctly and close the latches/ejectors on the card.
Note It is possible to close the latches/ejectors when the card is not completely plugged into the
backplane. Ensure that you cannot insert the card any further.
Step 4 If you have installed the AIC card, verify the following:
• The red FAIL LED turns on for 1 second, then blinks for 1 to 5 seconds.
• After 1 to 5 seconds, all LEDs blink once and turn off.
• The ACT LED turns on.
Step 5 If you have installed the AIC-I card, verify the following:
• The red FAIL LED turns on for 1 second, then blinks for 1 to 5 seconds.
• The PWR A and PWR B LEDs become red and the two INPUT/OUTPUT LEDs become green for
approximately 3 seconds.
• The PWR A LED turns green, the INPUT/OUTPUT LEDs turn off, and the ACT LED turns on.
Note It might take up to 3 minutes for the PWR A and PWR B LEDs to update.
Note If the red FAIL LED does not turn on, check the power.
Note If you insert a card into a slot provisioned for a different card, no LEDs turn on.
Purpose This task installs the Alarm Interface Controller (AIC) or Alarm Interface
Controller–International (AIC-I) card. The AIC or AIC-I card provides
connections for external alarms and controls (environmental alarms).
Tools/Equipment AIC or AIC-I card
Prerequisite Procedures DLP-A36 Install the TCC2/TCC2P Cards, page 17-42
DLP-A37 Install the XCVT or XC10G Cards, page 17-45
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
