18-40
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A167 Change Line and Threshold Settings for the DS3-12E or DS3N-12E Cards
Table 18-14 describes the values on the Provisioning > SONET Thresholds tabs for the DS3E cards.
Note The threshold value appears after the circuit is created.
Step 7 Return to your originating procedure (NTP).
AIS Alarm indication signal Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End only; DS3
CPbit: Near and Far End).
UAS Unavailable seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End only; DS3
CPbit: Near and Far End).
Table 18-13 Electrical Path Options for the DS3-12E and DS3N-12E Cards (continued)
Parameter Description Options
Table 18-14 SONET Threshold Options for DS3-12E and DS3N-12E Cards
Parameter Description Options
Port (Display only.) DS-3 ports partitioned for
STS
Line 1, STS 1, Line 2, STS 1
Line 3, STS 1, Line 4 STS 1
CV Coding violations Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
ES Errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
FC Failure count Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
SES Severely errored seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
UAS Unavailable seconds Numeric. Can be set for 15-minute or
one-day intervals. Select the bullet and
click Show Thresholds (Near and Far
End, STS termination only).
