21-27
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 21 DLPs A400 to A499
DLP-A498 Switch Between TDM and DWDM Network Views
Step 1 Disconnect the network fiber cable from the GBIC SC connector or SFP LC duplex connector. If the SFP
connector has a latch securing the fiber cable, pull it upward to release the cable.
Step 2 If you are using a GBIC with clips:
a. Release the GBIC from the slot by squeezing the two plastic tabs on each side of the GBIC.
b. Slide the GBIC out of the slot. A flap closes over the slot to protect the connector on the
Gigabit Ethernet card.
Step 3 If you are using a GBIC with a handle:
a. Release the GBIC by opening the handle.
b. Pull the handle of the GBIC.
c. Slide the GBIC out of the slot. A flap closes over the slot to protect the connector on the Gigabit
Ethernet card.
Step 4 If you are using an SFP:
a. If the SFP connector has a latch securing the fiber cable, pull it upward to release the cable.
b. Pull the fiber cable straight out of the connector.
c. Unplug the SFP connector and fiber from the card.
d. Slide the SFP out of the slot.
Step 5 Return to your originating procedure (NTP).
DLP-A498 Switch Between TDM and DWDM Network Views
Step 1 From the View menu, choose Go to Network View.
Step 2 From the Network Scope drop-down list on the toolbar, choose one of the following:
• All—Displays both TDM and DWDM nodes.
• TDM—Displays only ONS 15454s with SONET or SDH cards including the transponder (TXP) and
muxponder (MXP) cards.
• DWDM—Displays only ONS 15454s with DWDM cards, including the transponder and muxponder
cards.
Note For information about DWDM, TXP, and MXP cards, refer to the Cisco ONS 15454 DWDM
Installation and Operations Guide.
Purpose Use this task to switch between time division multiplexing (TDM) and
DWDM network views.
Tools/Equipment None
Prerequisite procedures DLP-A60 Log into CTC, page 17-66
Required/As needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
