17-21
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 17 DLPs A1 to A99
DLP-A18 Turn On and Verify Office Power
Note When terminating battery and battery return connections as shown in Figure 17-10, follow a
torque specification of 10 in-lb (0.12 m-kg).
Step 7 Terminate the return 1 lead to the RET1 backplane terminal. Use oxidation prevention grease to keep
connections noncorrosive.
Warning
Do not secure multiple connectors with the same bolt assembly.
Step 8 Terminate the negative 1 lead to the negative BAT1 backplane power terminal. Use oxidation prevention
grease to keep connections noncorrosive.
Step 9 If you use redundant power leads, terminate the return 2 lead to the positive RET2 terminal on the
ONS 15454. Terminate the negative 2 lead to the negative BAT2 terminal on the ONS 15454. Use
oxidation prevention grease to keep connections noncorrosive.
Step 10 Route the cables out below the power terminals using the plastic cable clamp, as shown in Figure 17-10
on page 17-20.
Step 11 Return to your originating procedure (NTP).
DLP-A18 Turn On and Verify Office Power
Step 1 Using a voltmeter, verify the office battery and ground at the following points on the fuse and alarm
panel:
a. To verify the power, place the black test lead of the voltmeter to the frame ground. Place the red test
lead on the A-side connection and verify that it is between –40.5 VDC and –57 VDC. Place the red
test lead on the B-side connection and verify that it is between –40.5 VDC and –57 VDC.
Note The voltages –40.5 VDC and –57 VDC are, respectively, the minimum and maximum
voltages required to power the chassis.
b. To verify the ground, place the black test lead of the voltmeter to the frame ground. Place the red
test lead on the A-side return ground and verify that no voltage is present. Place the red test lead on
the B-side return ground and verify that no voltage is present.
Step 2 Complete one of the following to power up the node:
If you are using a 80-A fuse panel, insert a 20-A fuse into the fuse position according to site practice.
Purpose This task measures the power to verify correct power and returns.
Tools/Equipment Voltmeter
Prerequisite Procedures DLP-A16 Connect the Office Ground to the ONS 15454, page 17-18
DLP-A17 Connect Office Power to the ONS 15454 Shelf, page 17-19
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
