21-16
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 21 DLPs A400 to A499
DLP-A438 Change General Port Settings for the FC_MR-4 Card
• OOS,MT—Puts the member cross-connects in the OOS-MA,MT service state. The maintenance
state does not interrupt traffic flow; it suppresses alarms and conditions and allows loopbacks to be
performed on the circuit. Use OOS,MT for circuit testing or to suppress circuit alarms temporarily.
Change the administrative state to IS; IS,AINS; or OOS,DSBLD when testing is complete.
• OOS,OOG—(LCAS and Software–Link Capacity Adjustment Scheme [Sw-LCAS] VCAT only.)
Puts VCAT member cross-connects in the Out-of-Service and Management, Out-of-Group
(OOS-MA,OOG) service state. This administrative state is used to put a member circuit out of the
group and to stop sending traffic.
Step 7 Click Apply.
Step 8 To close the Edit Circuit window, choose Close from the File menu.
Step 9 Return to your originating procedure (NTP).
DLP-A438 Change General Port Settings for the FC_MR-4 Card
Step 1 In node view, double-click the FC_MR-4 card where you want to change the port settings.
Step 2 Click the Provisioning > Port > General tabs.
Step 3 Modify any of the settings described in Table 21-3.
Purpose This task changes the general port settings for FC_MR-4 cards.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 21-3 FC_MR-4 Card General Port Settings
Parameter Description Options
Port (Display only.) Displays the port number. 1 through 4
Port Name Provides the ability to assign the
specified port a name.
User-defined. Name can be up to
32 alphanumeric/special characters.
Blank by default.
See the “DLP-A314 Assign a Name to a
Port” task on page 20-8.
