Cisco ONS 15454 Series - Table 18-12 Line Threshold Options for the DS3-12 E and DS3 N-12 E Cards; Table 18-13 Electrical Path Options for the DS3-12 E and DS3 N-12 E Cards

18-39
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A167 Change Line and Threshold Settings for the DS3-12E or DS3N-12E Cards
Table 18-13 describes the values on the Provisioning > Elect Path Thresholds tabs for the DS3E cards.
Table 18-12 Line Threshold Options for the DS3-12E and DS3N-12E Cards
Parameter Description Options
Port (Display only.) Port number 1 to 12
CV Coding violations Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds.
ES Errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds.
SES Severely errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds.
LOSS Loss of signal seconds; number
of one-second intervals
containing one or more LOS
defects
Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds.
Table 18-13 Electrical Path Options for the DS3-12E and DS3N-12E Cards
Parameter Description Options
Port (Display only.) Port number 1 to 12
CV Coding violations Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End only; DS3
CPbit: Near and Far End).
ES Errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End only; DS3
CPbit: Near and Far End).
SES Severely errored seconds Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End only; DS3
CPbit: Near and Far End).
SAS Severely errored frame/alarm
indication signal
Numeric. Can be set for 15-minute or one-day
intervals. Select the bullet and click
Show Thresholds (DS3 Pbit: Near End only; DS3
CPbit: Near and Far End).
