18-20
Cisco ONS 15454 Procedure Guide, R5.0
March 2007
Chapter 18 DLPs A100 to A199
DLP-A150 Modify a 1:1 Protection Group
Step 3 Return to your originating procedure (NTP).
DLP-A150 Modify a 1:1 Protection Group
Step 1 In node view, click the Provisioning > Protection tabs.
Step 2 In the Protection Groups area, click the 1:1 protection group you want to modify.
Step 3 In the Selected Group area, you can modify the following, as needed:
• Name—As needed, type the changes to the protection group name. The name can have up to
32 alphanumeric characters.
Table 18-2 Managing Domains
Domain action Steps
Move a domain Press Ctrl and drag and drop the domain icon to the new location.
Rename a domain Right-click the domain icon and choose Rename Domain from the shortcut
menu. Type the new name in the domain name field.
Add a node to a
domain
Drag and drop the node icon to the domain icon.
Move a node from a
domain to the
network map
Open the domain and right-click a node. Choose Move Node Back to Parent
View.
Open a domain Double-click the domain icon. Alternatively, right-click the domain and choose
Open Domain.
Return to network
view
Right-click the domain view area and choose Go to Parent View from the
shortcut menu.
Preview domain
contents
Right-click the domain icon and choose Show Domain Overview. The domain
icon shows a small preview of the nodes in the domain. To turn off the domain
overview, right-click the overview and select Show Domain Overview.
Remove domain Right-click the domain icon and choose Remove Domain. Any nodes in the
domain are returned to the network map.
Purpose This task modifies a 1:1 protection group for electrical (DS-1, DS-3, EC-1,
and DS3XM) cards.
Tools/Equipment None
Prerequisite Procedures DLP-A71 Create a 1:1 Protection Group, page 17-78
DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
