19-7
Cisco ONS 15454 Procedure Guide, R5.0
September 2005
Chapter 19 DLPs A200 to A299
DLP-A209 Change External Controls Using the AIC-I Card
Step 5 To provision additional devices, complete Step 4 for each additional device.
Step 6 Click Apply.
Step 7 Return to your originating procedure (NTP).
DLP-A209 Change External Controls Using the AIC-I Card
Note The procedure is the same if you are using the alarm expansion panel (AEP). In this case, the number of
contacts that are shown on the screen is changed accordingly.
Step 1 Verify the external control relays to the ENVIR ALARMS OUT backplane pins. See the “DLP-A19
Install Alarm Wires on the Backplane” task on page 17-22 for more information.
Step 2 In node view, double-click the AIC-I card to display it in card view.
Step 3 On the External Controls subtab, modify any of the following fields for each external control wired to
the ONS 15454 backplane. For definitions of these fields, see the “NTP-A258 Provision External Alarms
and Controls on the Alarm Interface Controller-International” procedure on page 7-11.
• Enabled
• Trigger Type
• Control Type
• Description
Step 4 To provision additional controls, complete Step 3 for each additional device.
Step 5 Click Apply.
Step 6 Return to your originating procedure (NTP).
Purpose This task changes external control settings on the AIC-I card.
Tools/Equipment None
Prerequisite Procedures DLP-A60 Log into CTC, page 17-66
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
